Programming Guide | VLT® AutomationDrive FC 301/FC 302
Table 46: Example of Setting up Triggers, Actions, and Readouts
ID
1391.8
1391.9
1392.0
1392.1
1392.2
1392.3
1392.4
1392.5
1392.6
1392.7
1392.8
1392.9
Example 1: In parameter 13-90 Alert Trigger, index [0], DI19 is selected as trigger. The digital value is 0000 0001. The corresponding
action, Info, is set in parameter 13-91 Alert Action, index [0] and is shown as 1 hex in parameter 13-99 Alert Status Word.
Example 2: In parameter 13-90 Alert Trigger, index [1], DI32 is selected as trigger. The digital value is 0000 0010. The corresponding
action, Warning, is set in parameter 13-91 Alert Action, index [1] and is shown as 2 hex in parameter 13-98 Alert Warning Word.
Example 3: In parameter 13-90 Alert Trigger, index [8], DI33 is selected as trigger. The digital value is 0001 0000 0000. The corresponding
action, Trip, is set in parameter 13-91 Alert Action, index [8] and is shown as 100 hex in parameter 13-97 Alert Alarm Word.
When 1 of the 3 digital inputs shown in this example is activated, the text shown in the LCP is the one defined in parameter 13-92 Alert
Text, index [0], [1], and [8].
The action setting of an active trigger cannot be changed. For example, if DI19 is selected as trigger and the input is high, the
action cannot be changed from Stop to Jog.
13-90 Alert Trigger
Default value: [0] False
Setup:
2 setups
Data type: Uint8
Select the event that triggers the user-defined action and message.
Option Name
[0]* False
[1] True
498 | © 2024.09
(continued)
Name
Alert Action
Alert Action
Alert Text
Alert Text
Alert Text
Alert Text
Alert Text
Alert Text
Alert Text
Alert Text
Alert Text
Alert Text
NOTICE
Parameter type:
Conversion index:
Change during operation:
Description
Parameter Descriptions
Setup 1
[12] Trip
[0] Info
Dig In 19
Dig In 32
User Alert
User Alert
User Alert
User Alert
User Alert
User Alert
Dig In 33
User Alert
Option, Array [10]
–
True
