Programming Guide | VLT® AutomationDrive FC 301/FC 302
Table 31: Digital Inputs, Function Descriptions - 4
Option
[119] Speed mode
[122] Position vir. master
[123] Master marker
[124] Master marker inv.
[125] Follower marker
214 | © 2024.09
(continued)
Function
This option is only available with software version 48.XX.
Select the speed mode when [9] Positioning or [10] Synchroniza-
tion is selected in parameter 1-00 Configuration Mode. Speed
reference is set by reference resource 1 or fieldbus REF1 relative
to parameter 3-03 Maximum Reference.
This option is only available with software version 48.XX.
Activates position-controlled virtual master when [10] Synchro-
nization is selected in parameter 1-00 Configuration Mode. When
the option is selected, the following occurs:
• Target position is set by Fieldbus Pos. Ref. or preset target is as
defined in parameter 3-20 Preset Target.
• Speed is set relative to parameter 3-27 Virtual Master Max Ref
by the source selected in parameter 3-15 Reference Resource 1
or fieldbus REF1.
• Acceleration and deceleration are set as defined in parameter
group 3-6* Ramp 3.
This option is only available with software version 48.XX.
Normally-open contact. Serves as input for master marker signal
during marker synchronization based on the option selected in
parameter 3-33 Sync. Mode & Start behavior.
This option is only available with software version 48.XX.
Normally-closed contact. Activates master marker signal
for marker synchronization based on the option selected in
parameter 3-33 Sync. Mode & Start Behavior.
This option is only available with software version 48.XX.
Normally-open contact. Serves as input for follower marker signal
during marker synchronization based on the option selected in
parameter 3-33 Sync. Mode & Start Behavior.
Parameter Descriptions
NOTICE
NOTICE
NOTICE
NOTICE
NOTICE
