User Interface
4.1.2 Setting LCP Display Values
The display area is activated when the frequency converter
receives power from mains voltage, a DC bus terminal, or
an external 24 V DC supply.
The information displayed on the LCP can be customized
for user application.
•
Each display readout has a parameter associated
with it
•
Options are selected in the quick menu Q3-13
Display Settings
•
Display 2 has an alternate larger display option
•
The frequency converter status at the bottom line
of the display is generated automatically and is
not selectable
Display
Parameter number
1.1
0-20
1.2
0-21
1.3
0-22
2
0-23
3
0-24
Table 4.1
Status
799 RPM
1.1
1.2
Auto Remote Ramping
2
3
Illustration 4.2
Status
207RPM
1.1
Auto Remote Running
Illustration 4.3
VLT
®
AQUA Drive D-Frame
Operating Instructions
Default setting
Motor RPMs
Motor current
Motor power (kW)
Motor frequency
Reference in percent
1 (1)
7.83 A
36.4 kw
0.000
53.2 %
1.3
1 (1)
5.25A
24.4 kW
6.9
Hz
1.3
1.2
2
®
MG21A202 - VLT
is a registered Danfoss trademark
4.1.3 Display
Menu keys are used for menu access for parameter set-up,
toggling through status display modes during normal
operation, and viewing fault log data.
Quick
Status
Menu
Illustration 4.4
Key
Function
Status
Shows operational information.
•
In Auto mode, press to toggle between
status read-out displays
•
Press repeatedly to scroll through each
status display
•
Press [Status] plus [
display brightness
•
The symbol in the upper right corner of the
display shows the direction of motor
rotation and which set-up is active. This is
not programmable.
Quick Menu
Allows access to programming parameters for
initial set up instructions and many detailed
application instructions.
•
Press to access Q2 Quick Setup for
sequenced instructions to program the basic
frequency controller set up
•
Follow the sequence of parameters as
presented for the function set up
Main Menu
Allows access to all programming parameters.
•
Press twice to access top-level index
•
Press once to return to the last location
accessed
•
Press to enter a parameter number for
direct access to that parameter
Alarm Log
Displays a list of current warnings, the last 10
alarms, and the maintenance log.
•
For details about the frequency converter
before it entered the alarm mode, select the
alarm number using the navigation keys
and press [OK].
Table 4.2
Main
Alarm
Menu
Log
▲
▼
] or [
] to adjust the
37
4
4
