TLSB Data Wrapping

2.2.8.6

ECC Coding

Data is protected using quadword ECC. The 256-bit data bus is divided
into four quadwords. Protection is allocated as follows:
Figure 2-3 shows the ECC coding scheme for TLSB_D<63:0> and
TLSB_ECC<7:0>. The same coding scheme is used for each of the other
three quadwords, and again for the four quadwords in the second data cy-
cle.
Figure 2-3

64-Bit ECC Coding Scheme

DATA 6666 5555
BITS 3210 9876
XOR S7 0000 0000
XOR S6 1111 1111
1111 1111
XOR S5
XOR S4 1100 0000
0011
1000
XNOR S3
1010 0110-
XNOR S2
0001 0101
XOR S1
1011 0100
XOR S0
7766 6666
HEX
50DB 8742
SYNDROME
CHECK
BITS 7654 3210
XOR S7 1000 0000
XOR S6 0100 0000
0010 0000
XOR S5
XOR S4 0001 0000
XNOR S3 0000
1000
XNOR S2
0000 0100
XOR S1
0000 0010
XOR S0
0000 0001
HEX
8421 0000
SYNDROME
0000 8421
TLSB_ADR<5>
0
0
1
1
• TLSB_D<63:0> is protected by TLSB_ECC<7:0>
• TLSB_D<127:64> is protected by TLSB_ECC<15:8>
• TLSB_D<191:128> is protected by TLSB_ECC<23:16>
• TLSB_D<255:192> is protected by TLSB_ECC<31:24>
