Table 7-9
Address Ranges Selected by ADRMASK Field Values
<ADRMASK>
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F (reserved)
Address
TLSB_ADR Bits
Range
Compared
64 Mbytes
<39:26>
128 Mbytes
<39:27>
256 Mbytes
<39:28>
512 Mbytes
<39:29>
1 Gbyte
<39:30>
2 Gbytes
<39:31>
4 Gbytes
<39:32>
8 Gbytes
<39:33>
16 Gbytes
<39:34>
32 Gbytes
<39:35>
64 Gbytes
<39:36>
128 Gbytes
<39:37>
256 Gbytes
<39:38>
512 Gbytes
<39>
1 Tbyte
-----
TLSB_ADR Bits
Masked
----
<26>
<27:26>
<28:26>
<29:26>
<30:26>
<31:26>
<32:26>
<33:26>
<34:26>
<35:26>
<36:26>
<37:26>
<38:26>
<39:26>
System Registers 7-23
