Tlvid Register Bit Definitions - DEC AlphaServer 8200 Technical Manual

Table 7-6

TLVID Register Bit Definitions

Name Bit(s)
<31:8>
RSVD
<7:4>
VID_B
<3:0>
VID_A
7-20 System Registers
Type Function
R/W, 0 Reserved. Must be written as zero.
R/W, 0 Virtual ID B. Contains the virtual ID for unit
B in this node. Reads zero if unimplemented.
CPU: Contains the virtual ID for CPU1. Initial-
izes to TLSB_NID<2:0> shifted left filled with
one. A read of this register reads the hardwired
value. However, the register must be written to
update the DIGA VID field.
Memory: Contains the virtual ID number for
memory bank 1. Console loads this field at in-
itialization time. The contents of this register are
compared to TLSB_BANK_NUM<3:0> during a
memory space command/address cycle to deter-
mine if bank 1 of this module is selected.
R/W, 0 Virtual ID A. Contains the virtual ID for unit
A in this node.
CPU: Contains the virtual ID for CPU0. Initial-
izes to TLSB_NID<2:0> shifted left filled with
zero. A read of this register reads the hardwired
value. However, the register must be written to
update the DIGA VID field.
Memory: Contains the virtual ID number for
memory bank 0. Console loads this field at in-
itialization time. The contents of this register are
compared to TLSB_BANK_NUM<3:0> during a
memory space command/address cycle to deter-
mine if bank 0 of this module is selected.
