TLRMDQRX—Memory Channel Decr Queue Counter
Register X
Address BSB + 0600
Access R/W
The TLRMDQR register X is used by an I/O node to inform all
nodes when a Memory Channel address register becomes avail-
able. One I/O port in physical nodes 4 through 7 that is enabled to
handle Memory Channel transactions issues writes to this register.
If the I/O node acknowledges the CSR write command, it must cy-
cle the data bus and provide data with good ECC. The data is con-
sidered Unpredictable and is not used by the receiver. The receiv-
ing nodes must decrement the counter whether the command is
acknowledged or not.
31
Unpredictable
0
BXB-0541V-93
System Registers 7-39
