7.3 TLSB Registers

Table 7-2 lists the TLSB registers. Descriptions of registers follow.
Table 7-2

TLSB Registers

Mnemonic Name
Device Register
TLDEV
Bus Error Register
TLBER
TLCNR Configuration Register
Virtual ID Register
TLVID
Memory Mapping Register
TLMMR0
Memory Mapping Register
TLMMR1
Memory Mapping Register
TLMMR2
TLMMR3 Memory Mapping Register
Memory Mapping Register
TLMMR4
Memory Mapping Register
TLMMR5
Memory Mapping Register
TLMMR6
Memory Mapping Register
TLMMR7
TLSB Failing Address Register 0
TLFADR0
TLFADR1 TLSB Failing Address Register 1
TLSB Error Syndrome Register 0
TLESR0
TLSB Error Syndrome Register 1
TLESR1
TLSB Error Syndrome Register 2
TLESR2
TLSB Error Syndrome Register 3
TLESR3
TLILID0 Interrupt Level0 IDENT Register
Interrupt Level1 IDENT Register
TLILID1
Interrupt Level2 IDENT Register
TLILID2
Interrupt Level3 IDENT Register
TLILID3
CPU Interrupt Mask Register
TLCPUMASK
TLMBPR Mailbox Pointer Register
Reserved for private transactions
TLPRIVATE
Interprocessor Interrupt Register
TLIPINTR
I/O Interrupt Register 4
TLIOINTR4
I/O Interrupt Register 5
TLIOINTR5
I/O Interrupt Register 6
TLIOINTR6
TLIOINTR7 I/O Interrupt Register 7
I/O Interrupt Register 8
TLIOINTR8
Window Space Decr Queue Counter Reg 4
TLWSDQR4
Window Space Decr Queue Counter Reg 5
TLWSDQR5
Window Space Decr Queue Counter Reg 6
TLWSDQR6
TLWSDQR7 Window Space Decr Queue Counter Reg 7
Window Space Decr Queue Counter Reg 8
TLWSDQR8
Mem Channel Decr Queue Counter Reg X
TLRMDQRX
Mem Channel Decr Queue Counter Reg 8
TLRMDQR8
CSR Read Data Return Data Register
TLRDRD
CSR Read Data Return Error Register
TLRDRE
TLMCR Memory Control Register
1 Virtual CPU ID asserted on TLSB_BANK_NUM<3:0> to select one of 16 actual registers.
2 Data not to be recorded by another node.
7-4 System Registers
Modules That
Address Implement
BB+0000 CPU, Mem, I/O
BB+0040 CPU, Mem, I/O
BB+0080 CPU, Mem, I/O
BB+00C0 CPU, Mem
BB+0200 CPU, I/O
BB+0240 CPU, I/O
BB+0280 CPU, I/O
BB+02C0 CPU, I/O
BB+0300 CPU, I/O
BB+0340 CPU, I/O
BB+0380 CPU, I/O
BB+03C0 CPU, I/O
BB+0600 Mem, I/O
BB+0640 Mem, I/O
BB+0680 CPU, Mem, I/O
BB+06C0 CPU, Mem, I/O
BB+0700 CPU, Mem, I/O
BB+0740 CPU, Mem, I/O
BB+0A00 I/O
BB+0A40 I/O
BB+0A80 I/O
BB+0AC0 I/O
BB+0B00 I/O
1
BB+0C00 I/O
2
BSB+0000 None
BSB+0040 CPU
BSB+0100 CPU
BSB+0140 CPU
BSB+0180 CPU
BSB+01C0 CPU
BSB+0200 CPU
BSB+0400 CPU
BSB+0440 CPU
BSB+0480 CPU
BSB+04C0 CPU
BSB+0500 CPU
BSB+0600 CPU, I/O
BSB+0640 CPU, I/O
BSB+0800 CPU
BSB+0840 CPU
BSB+1880 Memory
