DEC Network Integration Server 600
Installation and Service Manual
Order Number: EK-A0543-IN.001
This manual shows how to install and test the DEC Network Integration
Server 600 hardware system. It includes problem solving procedures and
describes how to remove and replace DEC Network Integration Server 600
components. It also contains important safety information.
It must be read by service personnel who install the DEC Network
Integration Server 600 and perform problem solving procedures.
Revision Information:
This is a new manual.
