The Mobile Card

The Mobile Card interfaces the ETERNITY GENX with 2G/3G/4G networks. It routes calls made and received over
mobile networks, like a mobile handset.
The Mobile Cards are available in 2G, 3G and 4G variants.
The Mobile Card does not support GPRS features, Fax and Data services, network supported services
except CLIR and USSD.
The Mobile card is available in the following configurations:
The Mobile Card for ETERNITY GENX
Card Name
ETERNITY GE Card GSM4
ETERNITY GE Card GSM4 3G
ETERNITY GE CARD GSM4
4G
Just like mobile handsets, each Mobile Port has a unique IMEI (International Mobile Equipment Identity) number,
pasted on the mobile engine.
SIM cards from different service providers can be used.
Antenna
ETERNITY GE Card GSM4 has a single antenna for the four ports. A splitter connects all the four ports on the card
into a single antenna. An antenna cable is also provided, giving you the flexibility to move the antenna to another
position (in case of weak signal).
59
Configuration and Application
4-port card to connect to 4 GSM networks (4 SIM Cards can be installed).To
know more, refer to "ETERNITY GE Card GSM4/ GSM4 3G without SIM Hot-
swap".
For Hardware Design V2R2, CPLD V2R2 and PCB V2R1
This version onwards SIM Hot Swap is supported, that is the SIM card can be
removed and inserted in the SIM Slots without turning off the system. To know
more, refer to "ETERNITY GE Card GSM4/ GSM4 3G/ GSM4 4G with SIM
Hot-swap".
4-port card to connect to 4 GSM networks with 3G support (4 SIM Cards can
be installed). To know more, refer to
without SIM Hot-swap".
For Hardware Design V2R2, CPLD V2R2 and PCB V2R1
This version onwards SIM Hot Swap is supported, that is the SIM card can be
removed and inserted in the SIM Slots without turning off the system. To know
more, refer to "ETERNITY GE Card GSM4/ GSM4 3G/ GSM4 4G with SIM
Hot-swap".
4-port card to connect to 4 GSM networks with 4G support (4 SIM Cards can
be installed). To know more, refer to
GSM4 4G with SIM Hot-swap".
"ETERNITY GE Card GSM4/ GSM4 3G
"ETERNITY GE Card GSM4/ GSM4 3G/
