The Dial Plan Table allows you to configure upto 64 entries. Each entry is stored against an Index number.
For each entry,
• In Destination Number, enter the number you expect the callers to dial. You may enter upto 64
characters (Digits +
[,], Hyphen [-], Caret [^ ]. Default: Blank.
• Click Submit to save.
If there are multiple entries in the Dial Plan table, to search a particular entry in the table, under Testing
enter the desired number to know which entry would be selected for routing.
Wildcard Characters
SARVAM UMG supports following characters.
Character
X (letter X)
#
*
+
[ - ]
[ , ]
[ ^ ]
T (letter T)
Refer the following table to understand how a Dial Plan can be configured.
Dial Plan Entry Description
1XX Allows you to dial any number in a range from 100 to 199.
[2-5]XX Allows you to dial any 3 digit number in a range from 200-599.
Allows you to dial any 3 digit number in the range from 200-299, 300-399, 800-
[2,3,8]XX
899.
[2-9]XXXXXX Allows you to dial any 7 digit number in the range from 2000000-9999999.
Allows you to dial a 4 digit number: 2301, 2311, 2331, 2341, 2351, 2361, 2371,
23[^2]1
2381, 2391.
2630[500-550] Allows you to dial a 7 digit number in the range from 2630500-2630550.
Allows you to dial a 2 digit number in the range from 00 to 99 except the numbers
[^6-7]X
from 60 to 79.
1234 Allows you to dial 1234 number only.
Matrix SARVAM UMG System Manual
"Wildcard Characters") in this field. Valid characters are 0 to 9, *, #, X, T, Comma
Description
X represents any single digit from 0 to 9.
When # is configured in a number string, it will not be considered as End of Dialing.
When * is configured in a number string, it will not be considered as End of Dialing.
+ (plus) can be configured as a first character of the Destination Number string in the
SIP Trunk-Destination Port Determination-Destination Number Based table only.
Hyphen within the bracket, defines a range. Only digits 0-9 are allowed within a bracket.
Comma within a bracket is used as a separator between the groups of numbers.
Caret within a bracket is used to deny or restrict the number or range defined after the
symbol. Only digits 0-9 are allowed after the caret.
Character T can be configured only as a last character in a number string. When
configured in a number string, the system waits for End of Dialing.
