• For SIP-1, select the Destination Port for Routing Calls as Fixed, and create Routing Group as
FXS Port.
• For FXS Port, select the Destination Port for Routing Calls as Fixed, and create Routing Group as
SIP Trunk 1 only.
For instructions on configuring SIP Trunk parameters, see
• Now, configure the Peer-to-Peer Table.
In this example, you would have to configure the Peer-to-Peer table as follows:
• At Location A, in the Number field of the Peer-to-Peer table, enter the Number you want to dial to call
the phone at Location B. In this case, 9898012345.
• For the number you entered, in the Destination Address field in the table, enter the IP Address of the
Router connected at Location B. In this case, 121.124.130.110
• The Peer-to-Peer table you configure for SETU VFXTH at Location A would look like this:
Instead of configuring the complete number string, you may configure only the prefix of the number to be
dialed as follows, the system will place all calls that start with '9898' to the IP Address 121.124.130.110.
Destination Number
No Match Found
9898
• At Location B, you need to do the following configuration in SARVAM UMG
• Select a SIP Trunk to be used for this application and enable it. For example, SIP Trunk 1.
• Set the SIP Trunk Mode of this trunk as Peer-to-Peer.
• Keep the SIP ID field of the SIP Trunk blank.
In the Router, you must configure the same SIP and RTP Ports as configured in the SARVAM UMG. In
other words, you must configure Port Forwarding for SIP and RTP on the Router.
• By default, Allowed IP Address for Incoming SIP Message is set to As per Peer to Peer table. In
the Peer to Peer table at Location B, you must configure the IP Address of the Router at Location A.
531
Destination Address
121.124.130.110
"SIP Trunk" under Basic Settings.
Name
Location B
