System Commands

Certain parameters of SARVAM UMG can be configured by dialing System Commands from a telephone
connected to the FXS Port. You can configure certain Network Parameters, like IP Address, Subnet Mask,
Connection Type, set the system to default and also view current IP Address, Subnet Mask, Connection Type, DNS
and Gateway Address by dialing System Commands.
To be able to view these details, the telephone connected to the FXS Port must have an LCD display.
To dial System Commands,
• Pick up the handset of the telephone connected to the FXS Port of SARVAM UMG.
• Dial #19-Command Password to enter programming mode.
You will get programming tone.
• To change WAN Port IP Address, dial 11-IP Address-#*
For example, to change IP address to 192.168.1.120, dial 11-192168001120-#*
Default: 192.168.1.100
• To change WAN Port Subnet Mask, dial 12-Subnet Mask-#*
Where,
Valid options are 0, 128, 192, 224, 240, 248, 252, 254 and 255.
For example, to change Subnet Mask to 255.255.254.0, dial 12-255255254000-#*
Default: 255.255.255.000
• To configure WAN Port Gateway IP Address, dial 13-Gateway Address-#*
Where,
Gateway IP Address is of 12 digits.
For example, to change Gateway Address to 192.168.9.10, dial 13-192168009010-#*
Default: Blank
To change Gateway IP Address to Blank, dial 13-#*
• To change LAN Port IP Address, dial 41-IP Address-#*
For example, to change IP address to 192.168.1.140, dial 41-192168001140-#*
Default: 192.168.2.100
• To change LAN Port Subnet Mask, dial 42-Subnet Mask-#*
Where,
Valid options are 0, 128, 192, 224, 240, 248, 252, 254 and 255.
For example, to change Subnet Mask to 255.255.253.0, dial 42-255255253000-#*
Default: 255.255.255.000
• To select the Connection type, dial 10-Code-#*
Where,
Code is 1 for Static, 2 for DHCP, 3 for PPPoE
Default: Static
• To enable/disable VLAN Tag, dial 31-Code-#*
Where,
Code is 1 for Enable, 2 for Disable
