Installing Eternity Genx - Matrix Telecom SARVAM UMG System Manual

CHAPTER 5
• The Matrix ETERNITY GENX is to be installed by persons trained and experienced in telecom wiring.
• The person installing the ETERNITY GENX must be familiar with trunks, physical wiring of the MDF on
both the exchange (Gateway) side and the line side (CO).
• When installing any equipment, make sure that you take all the necessary precautions for handling
electronic and electrical appliances. Follow proper procedures for static electricity, while handling the
system and its cards to prevent damage to the system and harm to yourself.
• Use a grounding mat and wear an anti-static strap/belt. Read the do's and don'ts listed in
ETERNITY GENX Platform and
• If you have complied with the requirements and instructions described in
now begin the installation of your ETERNITY GENX.
Firmware Version V1R3 and earlier
The Matrix ETERNITY GENX is shipped factory fitted with the Power supply card, the CPU Card in their respective
fixed slots (refer the section
The cards - BRI, T1E1PRI, GSM, CO, SLT - are shipped separately as per the order placed by individual
customers. These cards are installed in any of the universal slots.
If you upgrade the system firmware to V1R4 and later, the Expansion Slots license will be applicable for the
universal slots. No universal slots will be functional by default. You must purchase the SARVAM EXP4 SME license
to activate the universal slots as required.
After upgrading the system with V1R4, if required you can again downgrade the system to V1R3.In this,
case all the universal slots will be functional.
For details, see "Expansion Slots"
Firmware Version V1R4 and later
The Matrix ETERNITY GENX is shipped factory fitted with the Power supply card, the CPU Card in their respective
fixed slots (refer the section
Matrix SARVAM UMG System Manual

Installing ETERNITY GENX

Yourself".
"Know your SARVAM UMG").
under "License Management".
"Know your SARVAM UMG").
"Protecting
"Before You Start", you may
30
