• SARVAM UMG supports 8 Dial Plans with total 64 entries in each table. When a user dials a number, it
is compared with the Destination Number configured in the Dial Plan. If a match is found, the system
routes the call immediately without waiting for End of Dialing and if a match is not found, the system will
wait for the End of Dialing and then route the call as per the Destination Port Selection method
configured.
Select the Dial Plan table number you configured for this port. If you have not configured the Dial Plan
table you may do so now,
• Click Settings
• Configure the numbers in the table. For detailed instructions, see
• Set the duration of the First Digit Wait Timer. This is the duration for which you want the system to
wait for the caller to dial the destination number after the dial tone. Valid range is 01 to 99 seconds.
Default: 7 seconds.
• Set the duration of the Inter Digit Wait Timer. This is the duration for which you want the system to
wait while receiving the digits dialed by the caller to consider it as End of Dialing. You may change this
timer, if required. Valid range is 01 to 99 seconds. Default: 05 seconds.
• As End of Dialing Digit, select whether the system should consider # or * as termination digit to detect
end of dialing. Default: #
• In Minimum number of digits that can be dialed by the caller, select the minimum number of digits
to be dialed by the user for the system to consider it as a valid number. Valid range is 01 to 24 digits.
Default: 2 digits.
• In Maximum number of digits that can be dialed by the Caller, select the maximum number of digits
to be dialed by the user for the system to consider it as end-of-dialing. Valid range is 01 to 24 digits.
Default: 24 digits.
When the caller dials a number, the system will match it with the above end-of-dialing indications and
accept the one that matches first.
• If the caller fails to dial the number during the First Digit Wait Timer, you can either have the system
disconnect the call or route the call to a fixed destination number.
In If No Digit dialed during First Digit Wait Timer, you can select — Disconnect the Call or Use Fixed
Destination Number. Default: Disconnect Call.
• If you select Use Fixed Destination Number, enter the desired destination number in Fixed
Destination Number. The Destination number may consist of a maximum of 24 digits. Valid digits are
0 to 9, *, # and (.) dot. Default: Blank.
• Select the Allow making New Call using Access Code check box, if you want to enable the feature
Making New Call using Access Code on the FXO Port. See
• Click Submit to save settings.
Matrix SARVAM UMG System Manual
. The Dial Plan Table opens.
"Dial Plan".
"Making a New Call using Access Code".
