The cable wires may have to be crossed depending on the pinout of the DTE Interface of the modem.
Repeat the same steps to install another card. It is not necessary to install the other T1E1PRI cards in a
10.
sequence. Any card can be installed in any of the slots.
If you have completed all other installation tasks. Power the system. After the Reset Cycle, observe the
11.
LED patterns of the T1E1PRI Card.
LED Patterns
The ETERNITY GE Card T1E1PRI has 2 LEDs: L1 and L2. Given below are the LED Patterns defined for each port
state in different signaling types supported by the ETERNITY GENX.
1. Port Active Mode
Signaling Type: E1-PRI
LED1 Pattern:
Port Status
Layer 1 established successfully
CRC4 Alarm
BFA Alarm
LOS Alarm
LED2 Pattern:
Port Status
Layer 1 established successfully
RAI Alarm
AIS or LOS Alarm
Signaling Type: E1-CAS
LED1 Pattern:
Port Status
Layer 1 established successfully
CRC4 Alarm
MFA Alarm
BFA Alarm
LOS Alarm
67
Color
Cadence
GREEN
Continuous ON
GREEN
100ms ON-100 ms OFF
RED
500ms ON-500 ms OFF
RED
Continuous ON
Color
Cadence
GREEN
Continuous ON
RED
500ms ON-500 ms OFF
RED
Continuous ON
Color
Cadence
GREEN
Continuous ON
GREEN
100ms ON-100 ms OFF
RED
100ms ON-100 ms OFF
RED
500ms ON-500 ms OFF
RED
Continuous ON
Matrix SARVAM UMG System Manual
