The T1E1PRI Card

The ETERNITY GE Card T1E1PRI Single provides the interface to connect ETERNITY GENX to ISDN PRI
Network.
When connected to T1 carrier lines, the Card supports the following signaling types:
• PRI
• Robbed Bit Signaling (RBS)
When connected to E1 carrier lines, the card supports the following signaling types:
• PRI
• Channel Associated Signaling (CAS)
The T1E1PRI Card is available in the following configuration:
T1E1PRI Card for ETERNITY GENX
Card Name
ETERNITY GE Card T1E1PRI
Single
Connectors
The T1E1PRI card has an RJ45 Connector. A cable with RJ45 plugs on both ends is supplied for the connector.
LED
The ETERNITY GE Card T1E1PRI Single has 2 LEDs - L1 and L2 - for indicating the port states.
Installing the T1E1PRI Card
Before installing the card, take the necessary precautions prescribed for handling the cards. Always wear
1.
an electrostatic-discharge preventive wrist strap and use a grounding mat. Make sure the power supply is
turned off.
Unpack the T1E1PRI card and check the package contents.
2.
Select any free (empty) slot from the universal slots. Unscrew and remove the filler bracket of the empty
3.
slot. Do not discard the filler bracket.
Matrix SARVAM UMG System Manual
Configuration and Application
1-Port card to connect 1 ISDN T1/E1 PRI Line or ISDN Compatible Device
