• Enter the DSP Debug Parameter 1 value for which you require the debug. You can enter the
values from 000 to 255.
Value
000
001
002
003 to 255
Default is 000.
It is not possible to enable all these debugs at a time, only one of these can be enabled at a time.
• Enter the DSP Debug Parameter 2 value for which you require the debug. You can enter the
values from 000 to 255.
Value Meaning
000 Debug Off
001 Enable FXS Debug
002 Enable FXO Debug
004 Enable ISDN Debug
008 Enable GSM Debug
016 Enable Switch Debug
032 Enable Other Debugs (e.g. Slave HPI)
Default is 000.
• In DSP Syslog Server Address, enter the remote DSP Syslog Server Address. Default: Blank.
• In DSP Syslog Server Port, enter the port number. The range of the server port is 514, 1024 to
65535. Default: 514.
• In PCM Capture Port, select the desired port — FXO, Mobile, BRI, T1E1 and the respective port
number. Default: None.
• To start PCM Capturing for the desired port, click Start.
• To stop PCM Capturing for the desired port, click Stop.
Matrix SARVAM UMG System Manual
Meaning
Enables DSP Serial Real Time Debug
Enables DSP Serial Slow Debug
Enables DSP Ethernet Debug
Enables DSP Serial Slow Debug
