Ports and Connectors:
Port Connector
LAN RJ45
WAN RJ45
USB -
COM DB-9
If you buy a spare CPU Card separately, the default Pendrive will not be provided along with it.
LAN Interface
The LAN Port is provided to:
• connect a PC or a LAN Switch. This port is used for operating the web-based programming software,
Jeeves.
• capture "System Activity
WAN Interface
The WAN Port is provided to:
• connect a LAN Switch/Router/Modem.
• connect the CPU Card to the public network over a Router/Modem.
• register the SIP Trunks with the ITSP.
• capture "System Activity
VoIP Interface
The CPU Card supports two NX DBM VOCODER64 modules. You must purchase the module separately for VoIP
functionality.
VOCODER Channels
The system supports two NX DBM VOCODER64 Modules. Each module supports 64 Vocoder Channels
must purchase the modules separately. The system provides 4 pre-activated Vocoder channels by default which
can be used after installing NX DBM VOCODER64 module. If you require more channels, you can purchase the
licenses accordingly. Matrix provides two licenses — SARVAM VOCODER CHNL4 and SARVAM VOCODER
CHNL16.
If you require more than 64 Vocoder channels, you can install another NX DBM VOCODER64 Module.
4. During the Demo period, the number of Vocoder channels supported will be equal to the total number of channels available in the
Vocoder module/s installed in the System. If the Demo period is paused or gets expired, then the number of Vocoder channels sup-
ported would be as per the license you purchase.
39
Description
Used for connecting the Ethernet cable into LAN Port to connect to a PC or a LAN
Switch.
Used for connecting the Ethernet cable into WAN Port to connect to a Broadband
Router/Modem.
For future use
For future use
Log", "System Fault Log"
Log", "System Fault Log"
and "System Debug".
and "System Debug".
