Matrix Telecom SARVAM UMG System Manual page 565

If the Demo period is paused or gets expired, then the maximum number of SIP calls that will be supported would
be as per the license you purchase.
The system supports two NX DBM VOCODER64 Modules. You must purchase the module separately. Each NX
DBM VOCODER64 module supports a maximum of 64 Vocoder channels.
The system provides 4 pre-activated Vocoder channels by default which can be used after installing NX DBM
VOCODER64 module. If you require more channels, you can purchase the licenses accordingly.
If you require more than 64 Vocoder channels, you can install another NX DBM VOCODER64 Module.
During a SIP call, VOCODER channel is required and if no free channel is available, the system will reject the call.
Virtual User
This license is required for Virtual Users to access the Virtual Features on the Mobile Port remotely.
It is also required in the countries where the GSM Service Provider supports Called Number with Calling Number
using Separator.
Supported Licenses
Refer to the table below to know the name of the respective licenses you need to activate for each feature.
License Name
SARVAM UMG SME
SARVAM EXP4 SME
SARVAM VOCODER CHNL4
SARVAM VOCODER CHNL16
SARVAM Virtual User
Demo Provision
Demo provision is useful, when the customer's system cannot be repaired on-site and a standby system needs to
be installed Or when end users demand to use the licensed feature on trial basis before actually purchasing the
license.
Demo Provision enables you to use the SARVAM UMG application, free of cost for a period of 60 days. In this
case, the application starts even if you have not purchased the SARVAM UMG SME license.
All the Universal Slots will be functional during the Demo period irrespective of the number of activated SARVAM
EXP4 SME licenses.
During the Demo Provision you can access and use all the features and functionalities
application.
23. The number of Vocoder channels that will be supported in demo period will be equal to the total number of channels available in
the Vocoder module/s installed in the System.
559
Universal Media Gateway License for Small-Medium Enterprise.
License for SARVAM UMG SME to activate four Expansion Slots.
License for Vocoder Channels to support 4 simultaneous calls with
transcoding.
License for Vocoder Channels to support 16 simultaneous calls
with transcoding.
License to support 250 Virtual Users, Virtual features and
Separator feature.
Description
23
supported by the
Matrix SARVAM UMG System Manual
