Restoring Default LAN IP Address
To restore the Default LAN IP Address by changing the Jumper (J1) settings on the CPU Card,
• Switch off the power supply.
• Remove the CPU Card from the slot.
• Locate Jumper (J1) on the PCB of the CPU Card.
• Change the position of the Jumper from BC to AB (that is, from 'Normal' to 'Reset Login Password')
• Reinsert the CPU Card into the slot.
• Switch ON the system and wait for the system to initialize.
• Switch OFF the system and remove the CPU Card from the slot.
• Change the Jumper position from AB to the original position BC.
• Insert the CPU Card back into the slot.
• Switch ON the system.
The LAN IP Address will be restored to default, 192.168.2.100
When you restore the default LAN IP Address (192.168.2.100) by changing the Jumper position, a few
other parameters will also be set to default. See
Position" for details.
95
"Restoring Default Settings by changing the Jumper
