Mobile Port

The system supports a maximum of 48 Mobile ports. Before you begin configuring the Mobile ports, ensure that the
Mobile Card has been installed correctly. The system supports 2G, 3G as well as 4G LTE network thereby
providing higher bandwidth, greater connection speed and better underlying technology for VoIP calls. Access to
these networks is achieved by mounting any of these — 2G, 3G or 4G — GSM modules on the Mobile card.
Configuration of Mobile Port involves:
1. Customizing the Mobile Port Parameters
2. Network Selection
3. Configuring VoLTE parameters. For details refer to
4. Uploading MBN files, For details refer to
5. Viewing Mobile Port Status
To configure a Mobile Port,
• Click the Basic Settings link to expand.
• Click the Mobile Port link.
The Mobile Port page displays the following parameters:
• Port: It displays the Mobile Port numbers. Click on the desired Mobile Port number to configure the Port
Parameters.
• Hardware Slot-Port: The SARVAM UMG can automatically detect and assign the Hardware Slot and Port
numbers to the Mobile software ports. However, if required you may change the Hardware Slot and Port
assigned to the Mobile software port. In this case, enter the desired Hardware Slot and Port number.
• Enable: Keep the Mobile Ports enabled. Clear the Mobile Port Enable check box, only if you do not want
to use the respective port. Default: Enabled.
Matrix SARVAM UMG System Manual
"VoLTE Configuration".
"MBN File Upload".
