Advanced
•
Timer
•
If you select Peer-to-Peer, you must configure the following parameters:
•
Enable Peer-to Peer option and configure the Peer-to-Peer Dialing table
•
Allowed IP Address for Incoming SIP Message
•
Digest Authentication
•
Codec
•
VoIP Profile
•
Advanced
Peer-to-Peer Table
By default Peer-to-Peer is selected as the SIP Trunk Mode. You must configure the Peer-to-Peer Table.
To do so,
•
Click Settings
•
The Peer-to-Peer Dialing table opens.
•
You can add maximum 500 entries. Each entry in the table consists of the Destination Number,
Destination Address and Name. For detailed instructions, see
Allowed IP Address for Incoming SIP Message
If you have selected the SIP Trunk Mode as Peer-to-Peer, you must select the desired option in Allowed IP
Address for Incoming SIP Message — As per Trusted IP Address table, As per Peer-to-Peer table or Any.
•
If you select As per Trusted IP Address table option, the system matches the IP Address: Port received
in the INVITE message (Source IP address from the Network layer and Source Port from the Transport
layer) with the entries configured in the Trusted IP Address table. If a match is found, the call will be routed
to the desired destination. Else the call will be rejected.
You must configure the Trusted IP Address Table to receive incoming calls on this SIP Trunk. If you do
not configure this table, incoming calls on this SIP Trunk will be rejected.
You can configure maximum 10 entries in the Trusted IP Address table.
Matrix SARVAM UMG System Manual
.
"Peer-to-Peer Dialing".
490
