Select the required option for sending the Called-Numbering Plan Identification (NPI) — Unknown,
ISDN Numbering, Data Numbering, Telex Numbering, National Numbering, Private or Reserved.
Default: ISDN Numbering.
•
Select the Send Progress Indicator (PI) in SETUP message check box if you want the progress
indicator value to be sent in SETUP message. Default: Disabled.
•
Set the Progress Indicator (PI) value in SETUP message to the desired value. You can select — 1 or
3.
Progress indicator 1 indicates that the call is not end-to-end ISDN and further call progress information
may be available in-band.
Progress indicator 3 indicates that the origination address is non-ISDN.
This value will be included in the Setup Message to indicate whether the calling party is an ISDN device
or not. Default: 1.
•
Select the Progress Indicator (PI) Location for the SETUP message.The location is a progress
indicator information element that indicates from where the message is coming. Default: Public
Network serving the local user.
•
Select the Send Presentation Indicator and Screening Indicator check box, if you want the system
to display the presentation and screening information to the remote end. Default: Disabled.
•
Select the required Presentation Indicator. This allows remote end to know whether CLI Number
should be displayed to user or not. You can select — Presentation Allowed, Presentation Restricted
or Received from Source Port. Default: Received from Source Port.
•
Select the required Screening Indicator. This indicates whether the information is provided by the
user or the network along with the screening details — not screened, verified and passed or verified
and failed. Default: User-provided, not screened.
•
Select the Bearer Service supported by your service provider. This will be sent in the SETUP
Message. You can select — Speech, 3.1 KHz Audio. Default: Speech
•
Select the B - channel selection when SETUP message is received
•
Select the Progress Tone on Disconnect check box, If you want the system to play the progress tone
on the T1E1 Port when call is released by the remote end or released by the system. Default: Disabled.
•
Select the Send SETUP_ACK with PI check box, if you want the system to send PI (Progress
indicator) element in Setup Ack message. Default: Disabled.
•
Select the Send CALL PROCEED with PI check box, if you want the system to send PI (Progress
indicator) in Proceed message. Default: Disabled.
•
Select the Send ALERT with PI check box, if you want the system to send PI (Progress indicator) in
Alert message. Default: Disabled.
•
Click Submit to save changes.
15. This parameter is not applicable in this version, it is meant for future use.
387
15
as per your requirement.
Matrix SARVAM UMG System Manual
