License Management - Matrix Telecom SARVAM UMG System Manual

License Management

What's this?
The application SARVAM UMG and Vocoder Channels that it supports, require the purchase of licenses. When you
buy the ETERNITY GENX Platform, you get a default license key for the platform.
SARVAM UMG Application License
To use ETERNITY GENX as the Universal Media Gateway, you need to purchase the SARVAM UMG SME
Application software license.
If you do not have the license for the SARVAM UMG SME Application and you do not start the Demo
Period, the system will allow configuring and making of calls, but the connected calls
be disconnected after 60 seconds. For details, refer
Described below are the features of SARVAM UMG for which you require licenses. To know the name of the
license you need to purchase, see
Expansion Slots
Expansion Slots License is required to expand the number of functional universal slots in the system. This license
is applicable only for Firmware version V1R4 and later.
If you have upgraded the system firmware to V1R4 and later in the old ETERNITYGENX system, the Expansion
Slots license will be applicable for the universal slots. No universal slots will be functional by default. You must
purchase the license to activate the universal slots as required.
After upgrading the system with V1R4, if required you can again downgrade the system to V1R3.In this,
case all the universal slots will be functional.
If you have purchased the new ETERNITY GENX system with the firmware V1R4 and later, the Expansion Slots
license will be applicable for the universal slots. The first four universal slots after the power supply card will be
functional by default.
System purchased with V1R4 firmware must not be downgraded to earlier versions.
If you require more functional universal slots, you must purchase the Expansion Slots License to activate the same.
Matrix provides the expansion slot license — SARVAM EXP4 SME for ETERNITY GENX system.
Each SARVAM EXP4 SME license will provide the activation for next four universal slots in the sequence.
VOCODER Channels
Vocoder Channels license is required for SIP calls. The number of Vocoder channels that will be supported in demo
period will be equal to the total number of channels available in the Vocoder module/s installed in the System.
22. Connected calls means where speech is connected between the calling party port and the called party port even if the called party
port is not matured.
Matrix SARVAM UMG System Manual
"Supported Licenses".
"Demo Provision".
22
from any port will
558
