• Call Rejected, No Indication specifies the Group B backward tone used to inform the outbound end
that the call is rejected but there is no indication of cause. Valid range is 00/ 01 to 15. Default: 00. If this
parameter is not applicable, assign 00.
• Alternative Answer Tone specifies the Group B backward tone used to inform the outbound end that
the call is accepted and the speech path is made through. Valid range is 00/ 01 to 15. Default: 00. If this
parameter is not applicable, assign 00.
• Changed Number specifies the Group B backward tone used to inform the outbound end that the
number dialed by the calling party is changed. However, this parameter is rarely used. Valid range is
00/ 01 to 15. Default: 00. If this parameter is not applicable, assign 00.
Backward Group C
• Send Next ANI Digit specifies the backward group C tone to request next (even first) ANI digit from the
outbound end. Valid range is 00/ 01 to 15. Default: 00. If this parameter is not applicable, assign 00.
• Request Transition Back to Group A and Restart from First DNIS (Group C) specifies the
backward group C tone to restart from the first DNIS and request transition to Group A. Valid range is
00/ 01 to 15. Default: 00. If this parameter is not applicable, assign 00.
• Address Completed Change to Reception of Group B specifies the backward group C tone used to
signify Address completed, change to reception of Group B signal. Valid range is 00/ 01 to 15. Default:
00. If this parameter is not applicable, assign 00.
• Congestion specifies the backward group C tone used to signify Congestion. Valid range is 00/ 01 to
15. Default: 00. If this parameter is not applicable, assign 00.
• Request Transition Back to Group A and Sent Next DNIS specifies the backward group C tone
used to signify request transition back to group A, and send next DNIS. Valid range is 00/ 01 to 15.
Default: 00. If this parameter is not applicable, assign 00.
• Request Transition Back to Group A and Repeat the Last DNIS specifies the backward group C
tone used to signify request transition back to group A, and repeat the last DNIS. Valid range is 00/ 01
to 15. Default: 00. If this parameter is not applicable, assign 00.
Line Signal Parameters
• By default Line Signaling check box is enabled. If you are unable to make outgoing calls, check with
your Service Provider and disable this option.
• C and D Bits indicates the default values of C and D bits when the T1/E1 Port transmits line signals.
CD Bits
0
1
2
3
Default: 01 i.e. C=0 and D=1
449
Meaning (Binary Value)
00 (C=0, D=0)
01
10
11
