IP Dialing

SARVAM UMG supports direct dialing of IP Addresses from the source port. To provide IP Dialing facility to the
users, you must configure a SIP Trunk or a SIP Group for IP Dialing.
When a number is dialed out from the source port, SARVAM UMG routes the call to the desired destination as per
the routing mechanism configured for that port. However, when an IP Address is dialed from the source port of
SARVAM UMG, the system does not check the Destination Port Determination method you have configured for
that port, instead it routes the dialed IP Address through the SIP Trunk or the SIP Group you configured for IP
Dialing.
When dialing an IP Address, users must press * key (star/asterisk) in place of. (dot/period) in the IP Address.
For example, to call the IP Address 192.167.100.1, users must dial 192*167*100*1 or 192*167*100*001
SARVAM UMG interprets the * dialed as a '.' (dot / period).
Configuring IP Dialing
To provide this feature to users,
• you need to select a SIP Trunk or a SIP Group through which the dialed IP Addresses are to be routed.
If you want to use a SIP Trunk group for IP Dialing, you must configure a SIP Group first. This Group is
common for all port types. For instructions, see
When you assign a SIP Trunk, make sure it is enabled and has the necessary configuration done. For
instructions, see
• assign the SIP Trunk you want or the SIP Group you configured to SIP Trunk for IP Dialing in the System
Parameters. For instructions, see
is selected for IP Dialing in the System Parameters.
If the SIP Trunk Group for IP Dialing is programmed as 'None', SARVAM UMG will give error tone to the
caller; the call will be rejected.
Matrix SARVAM UMG System Manual
"SIP Trunk" under Basic Settings.
"System Parameters"
"Group" under Advanced Settings.
under Advanced Settings. By default, SIP Group 1
