ETERNITY GE Card SLT20
Connector Color
RJ45-1
1
RJ45-2
2
RJ45-3
3
RJ45-4
4
RJ45-5
5
RJ45-6
6
ETERNITY GE Card SLT16
71
Connection
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
H/w Port Offset
SLT 01
SLT 02
SLT 03
SLT 04
SLT 05
SLT 06
SLT 07
SLT 08
SLT 09
SLT 10
SLT 11
SLT 12
SLT 13
SLT 14
SLT 15
SLT 16
SLT 17
SLT 18
- -
- -
SLT 19
SLT 20
- -
- -
