Few examples of the Filter Settings are provided to you on this page to help you set the Filters as per your
requirement.
It is not mandatory to set Filters. When the Filter Settings left blank, the system will capture all packets.
• You may enable Promiscuous Mode by selecting the check box. Default: Disabled.
When you enable Promiscuous Mode, the SARVAM UMG will capture all network traffic. However, this will
work only in a non-switched environment.
When Promiscuous Mode is disabled, the system will capture only traffic that is directly related to it. Only
traffic to, from or routed through the SARVAM UMG will be picked up by the PCAP Trace.
'Filter Settings' and 'Promiscuous Mode' (enabled) will not be cleared during power down.
• You may enable RTP PCAP by selecting the Enable RTP PCAP check box. Default: Disabled.
If you want SARVAM UMG to capture RTP packets during PCAP for SIP calls, make sure you enable RTP
PCAP check box.
• Click the Start button to begin the capturing of the packets.
• Click the Stop button to stop packet capture.
OR
Wait for the system to stop packet capturing. The system stops packet capturing once the maximum
allotted memory of 10 MB (RAM) is utilized.
The Number of Packets and bytes captured as per the filter setting will be displayed in the fields Packets
Captured and Total Bytes respectively.
The Status field displays the current activity of packet capturing.
Capturing of packets will not stop if you open any other page of Jeeves. So, you may continue using
Jeeves for any other purpose while PCAP Trace is being used.
• When the packet capturing is stopped (by you or the system), click the Save Trace File button to save the
files on your computer or on another computer.
A dialog box opens. You can select the path for saving the trace file.
The current packets captured will not be deleted after you have saved the trace file. The current packets
will be deleted when you start the PCAP capture again.
• After logging out of Jeeves, you can open the trace files using Wireshark/ Ethereal or any other software
which supports opening of trace files.
