Select any free (empty) slot from the universal slots. Unscrew and remove the filler bracket of the empty
3.
slot. Preserve the filler bracket for future use!
Insert the CO Card into the guide rails of the free slot you selected for the card. The connectors on the card
4.
should make perfect contact with those of the slot on the backplane motherboard.
Press down the lever on the card mounting brackets to secure the card in its slot. Fix the mounting bracket
5.
in place with the two screws provided.
If installing more than one CO Card, it is not necessary to insert the other cards in subsequent slots. Any
card can be inserted in any of the universal slots.
Use the cables supplied for each connector on the CO card to connect the Trunk Lines with the Main
6.
Distribution Frame.
Refer the illustrations below for the pinout details of the connectors on each card.
ETERNITY GE Card CO16
L1 L2
Connector Color
RJ45-1
1
RJ45- 2
2
RJ45- 3
3
RJ45- 4
4
Matrix SARVAM UMG System Manual
Connection H/w Port Offset
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
CO 01
CO 02
CO 03
CO 04
CO 05
CO 06
CO 07
CO 08
CO 09
CO 10
CO 11
CO 12
CO 13
CO 14
CO 15
CO 16
