If you select MFC R2, DNIS/ANI is transmitted in the corresponding speech channel using the MFC R2
signals as per ITU-T Q.400-Q490.
Register Signal Parameters
• Set the duration of the Forward Tone Maximum On Timer (T1). This specifies the maximum time for
which the forward signal must remain ON from the outbound end. Valid range is 01 to 99 seconds.
Default: 15 seconds.
• Set the duration of the Forward Tone Maximum Off Timer (T2). This specifies the maximum time
between two outgoing forward signals. Forward tone remains OFF during this time.Valid range is 01 to
99 seconds. Default: 24 seconds.
• Set the duration of the Maximum Compelled Cycle Timer (T3). This specifies the maximum time
within which one compelled signaling cycle shall end. Valid range is 01 to 99 seconds. Default: 15
seconds.
• Set the duration of the Pulse Duration for Pulse Signal. This specifies the pulse duration of the
backward signals — A-3, A-4, A-6 and A-15 — that are pulsed to the outbound end. Pulse duration of
these signals vary from country to country. Valid range is 001 to 999 msec. Default: 150 msec.
It is recommended that tolerance be fixed at +/- 25 msec.
• Set the duration of the Pulsed Signal Maximum Wait Timer. This specifies the time for which the
outbound end waits for the pulsed signal. If the pulsed signal is not received during this time, the
compelling signaling is said to be complete. Valid range is 01 to 99 seconds. Default: 15 seconds.
• Set the duration of the First Forward Tone Wait Timer. This specifies the time between receipt of line
seizure signal and the first forward signal. Valid range is 08 to 24 seconds. Default: 15 seconds.
• Set the duration of the Minimum MF Signal Persist Timer. This specifies the minimum time for which
the forward /backward signal shall be sustained on the line by the receiving end. Valid range is 001 to
255 msec. Default: 20 msec.
Outbound Parameters
• Dialed Number Identification Signal (DNIS) End Type specifies the DNIS End Type as per your
requirement. This parameter is applicable only when DNIS length is set to 99 (i.e. variable). The
outbound end indicates end of DNIS using a group I tone or using time out.
Valid range is 00 to 15; where 00 indicates End of DNIS as time out. 01 to 15 indicates group I tone to
declare End of DNIS. Default: 15.
• Address Number Information (ANI) Send Position specifies the number of DNIS digits after which
address number information is to be sent. Address number information is usually sent on receiving the
backward tone Send next digit or Send next ANI digit.
If send next address number information tone is received then this parameter is not applicable. But if
same tone is used by the inbound end to request the next ANI digit and the next DNIS digit, ANI is sent
after the number of digits as set in this field. Valid range is 00 to 99. Default: 00.
• Address Number Information (ANI) Available signifies Group A tone (received from the inbound
tone) that is to be interpreted as a question by the inbound end asking the outbound end whether the
outbound end has ANI digits to be sent. Valid range is 01 to 15. Default: 05.
