Status Message
Network
Connection
Disable
Inactive
Registration Time: The SIP Trunk is registered with the Registrar Server for a particular time period,
after which it has to be re-registered. The registrar server indicates the time remaining for re-
registration of the SIP Trunk. The same is displayed in this field as Registration Time.
Registration Retry Count: This displays the total number of register messages which are sent to the
registrar server for registering the SIP Trunk.
Failed Reason: This displays the reason for failure of SIP Trunk registration with the registrar server.
The different reasons for registration failure that may appear are:
Failure Message
Message send fail
Failed to create Register client
Failed to detach register client
Failed to send request
Local Failure
Response timeout
Error Response- 4xx to 6xx
No contact header in 2xx
Authentication Failed
STUN address is not
programmed
STUN query fail
Outbound address is not
programmed
Router's IP address is not
programmed
Remote Peer Not Alive
Matrix SARVAM UMG System Manual
Meaning
The SIP Trunk is enabled but the active Network Connection does not match
the option selected for Use SIP Trunk for Network Connection parameter.
The Proxy Server is unavailable (no response is received from the server).
Description
This reason is displayed when registration request sent to
registrar server fails.
This reason is displayed when SIP stack has memory constraints,
or resource limitation or the number of SIP clients to register is
greater than the number programmed in the stack.
This reason is displayed when SIP stack has memory constraint/
resource limitation/ the number of SIP clients to register is greater
than the number programmed in the stack.
This reason is displayed when DNS server is not programmed.
This reason is displayed when DNS query fails.
This reason is displayed on the expiry of the General Request
Timer.
This is the error response code.
This reason is displayed when no contact address is received in
the 2xx response from the SIP server.
This reason is displayed when the SIP server does not
authenticate the client.
This reason is displayed when STUN is enabled but address is
not configured.
This reason is displayed when a query to the STUN server fails.
This reason is displayed when Outbound is enabled but
Outbound address is not configured.
This reason is displayed when Router's IP Address is to be used
in signaling but the address is not programmed.
This reason is displayed when no response is received from the
remote peer for the OPTIONS message.
702
