• To do this,
• Select the Apply check box.
• Follow the same instructions provided earlier for creating sequential and not-sequential groups of FXS
Ports, FXO Ports, Mobile Ports, BRI Ports, T1E1 Ports and SIP Trunks.
• Click Submit to save changes. The Edit window closes.
• The entry you edited appears in the Destination Port/Group for BRI Port window.
• Close the Destination Port/Group for BRI Port window to return to the Handling of Calls window.
On the basis of Destination Number
In this method, incoming calls on the source port are routed to the destination port on the basis of the destination
number (called party number) dialed by the caller.
You must configure the called party numbers in the Destination Number Based Table. SARVAM UMG will match
the called party number dialed by the caller with the entries of this table. If a match is found for the number in the
table, the call is routed to the destination.
To apply this method, do the following:
• In Select Destination Port for routing calls, select On the basis of Destination Number option.
• Click Settings
