Connecting ETERNITY GENX to the Earth
Follow the instructions given below to connect the ETERNITY GENX to the Earth. The instructions are given with
reference to the above diagram:
Loosen the screw.
1.
Insert an earthing wire into the lug.
2.
Crimp the earth wire with an appropriate tool.
3.
Tighten the screw.
4.
Connect the earthing wire to the earth.
5.
Make sure you use an earthing wire that has a conductor with a cross-sectional area greater than 1.0
mm2 or AWG less than or equal to 16 AWG with Green and Yellow insulation.
• Make sure you comply with all applicable laws, regulations and guidelines.
• Proper earthing is very important to protect the ETERNITY GENX from external noise and to reduce
the risk of electrocution in the event of a lightning strike.
• The AC cable's earthing pin may not be enough to protect the ETERNITY GENX from external noise
and lightning strikes. A permanent connection must be made between earth and the earth terminal of
the main unit.
