Insert the stripped ends of the two wires into the two (green-color) openings of the connector, with one wire
10.
in each opening.
Release pressure on the levers. Both wires will be held in place by spring clamp action.
11.
To remove the wires,
• push back the levers.
• pull out the wires gently.
• release pressure on the levers.
Now, repeat the above steps to connect the other CO Trunk wires from the CO side into the connectors of
12.
the ports P2, P3, and P4.
Now, terminate the wire pairs emerging from the PPM4 multi-pair cable into the 'Trunk Lines' side of the
13.
MDF using the punch tool for Krone Modules.
Refer the following table for connection details of the wires:
PPM4 Port
P1
P2
P3
P4
Replace the cover of the PPM4 by pressing back the snap fits on both sides.
14.
Mount the PPM, if not done already.
15.
25
Color
Blue and White
Orange and White
Green and White
Brown and White
