To apply this method, do the following:
• In Route all Incoming calls (with CLI), select after Answering the Call and Collecting the Digits.
The related parameters of this method appear under Answering the call and collecting the digits.
• If you want to enable PIN Authentication on the T1E1 Port, select the Prompt caller to enter PIN
check box.
If you enable this check box, you must also configure the PIN Authentication Table. To know more
about this feature and for detail instructions, see
• SARVAM UMG supports 8 Dial Plans with total 64 entries in each table. When a user dials a number, it
is compared with the Destination Number configured in the Dial Plan. If a match is found, the system
routes the call immediately without waiting for End of Dialing and if a match is not found, the system will
wait for the End of Dialing and then route the call as per the Destination Port Selection method
configured.
Select the Dial Plan table number you configured for this port. If you have not configured the Dial Plan
table you may do so now,
• Click Settings
• Configure the numbers in the table. For detailed instructions, see
• Set the duration of the First Digit Wait Timer. This is the duration for which you want the system to
wait for the caller to dial the destination number after the dial tone. Valid range is 01 to 99 seconds.
Default: 7 seconds
• You may configure the following options as End of Dialing indication:
• Set the duration of the Inter Digit Wait Timer. This is the duration for which you want the system to
wait while receiving the digits dialed by the caller to consider it as End of Dialing. You may change
this timer, if required. Valid range is 01 to 99 seconds. Default: 05 seconds.
• In End of Dialing Digit, select # or * as termination digit the system should consider to detect end
of dialing. Default: #
• In Minimum number of digits that can be dialed by the caller, select the minimum number of
digits to be dialed by the user for the system to consider it as a valid number. Valid range is 01 to 24
digits. Default: 2 digits.
• In Maximum Number of digits that can be dialled by the caller, select the maximum number of
digits to be dialed by the user for the system to consider it as End of Dialing. Valid range is 01 to 24
digits. Default: 24 digits.
When the caller dials a number, the system will match it with the above End of Dialing indications
and accept the one that matches first.
• If the caller fails to dial the number during the First Digit Wait Timer, you can either have the system
disconnect the call or route the call to a fixed destination number.
Matrix SARVAM UMG System Manual
. The Dial Plan Table opens.
"PIN Authentication" under Advanced Settings.
"Dial Plan".
