Insert the Mobile card into the guide rails of the universal slot you have selected for this card. Make sure
9.
that the card is inserted deep enough to make perfect contact with the connectors on the backplane. Now,
press down the levers on the card mount bracket to secure the card in its slot.
Connect the antenna provided with the card on the splitter connector on the front panel of the card. You
10.
may also use the antenna cable to place the antenna at another position.
If you have completed all installations tasks, power the system.
11.
Wait for the system to register with the Mobile network. By default, the Mobile ports are set to select and
12.
register with the Mobile networks automatically. Now, observe the LED Patterns of the Mobile Ports.
• At every power up of the system, it takes about 3 minutes for the Mobile ports to get registered with the
network. Once registration with the GSM network is completed, the mobile port can be used.
• Each time the Mobile Port sends a request, such as Registration Request, the system waits for the
duration of the Network Response Timer. This Timer signifies the time for which the Mobile Port waits
for a response from the Mobile network. It is fixed as 150 seconds for all Mobile ports.
LED Pattern of Mobile Ports
ETERNITY GE GSM4 Card has 4 tri-colour LEDs. The number of LEDs on the GSM card corresponds with the
number of mobile ports on the card.
After the Reset cycle is complete, during normal functioning, the LEDs color and cadence is described in the table
below for various events on the Mobile port:
Event
Port idle
Port Active (All States other
than Ring and Speech)
Ring Event
Speech
GSM initialization
PUK required
SIM PIN faulty
SIM Absent
Network Link Down
(Absence of GSM Network)
63
Color Cadence in msec (1 cadence is of 3000 msec)
- LED OFF
Red Continuous ON
Green 400ms ON-200ms OFF400ms ON-200ms OFF
Green Continuous ON
Orange 200ms ON-200ms OFF-200ms ON-200ms OFF-200ms ON-200ms
OFF-200ms ON-200ms OFF-200ms ON-1200ms OFF (5 blinks)
Orange 200ms ON-200ms OFF-200ms ON-200ms OFF-200ms ON-200ms
OFF-200ms ON-1600ms OFF-
Orange 200ms ON-200ms OFF-200ms ON-200ms OFF-200ms ON-2000ms
OFF (3 blinks)
Orange 200ms ON-200ms OFF-200ms ON-2400ms OFF (2 blinks)
Orange 200ms ON-2800ms OFF
