Configuring Call Detail Record Filters
• Click the Advanced Settings link to expand.
• Click Filters under Call Detail Record (CDR) link.
Setting Filters
• To set the filters, click the Filters link under Call Detail Records (CDR).
By default, all the filters are enabled. You may disable the filter you do not want to use by clearing the
related Apply Filter check box.
Some of these filters are enabled by default, you cannot disable them, but you can set them.
• Set the following filters as required:
The filters you set are not applied on the downloaded report. The CSV and TXT files will contain all the
records, irrespective of the filters you set.
• Calls originated from FXS Ports: The system will generate report of outgoing calls made from the
FXS Ports of SARVAM UMG. To generate report using this filter for both FXS Ports, set the range of the
FXS Ports in the From and To fields.
You can also generate report for a single FXS Port, by setting the same port number in the From and
To fields.
• Calls originated from SIP Trunks: The system will generate report of calls that were received on the
SIP Trunks of SARVAM UMG for further routing. To generate report using this filter for a range of SIP
Trunks, select the range of the SIP Trunks in the From and To fields.
You can also generate report for a single trunk, by setting the same trunk number in the From and To
fields.
