To be able to connect Single Line Telephones as Extensions to your ETERNITY GENX, you must install at least
one of the above mentioned SLT cards in the System.
Decide the number of SLT extensions required and arrange for as many telephone instruments.
1.
You may use any standard telephone instrument like a rotary phone, a pulse-tone switchable push-button
phone, a feature phone or a cordless phone.
Use SLTs equipped with a 'Flash' key, as several of the features and facilities of the SARVAM UMG
require you to press Flash. If any of the SLTs you have selected does not have a Flash key, tap the Hook
switch of the phone to dial Flash.
Unpack the SLT card and check the package contents. Ensure that the power supply is switched off,
2.
before you begin the installation of the card. Always wear an electrostatic discharge prevention wrist strap/
belt and use a grounding mat.
Unscrew and remove the filler card mount bracket of any of the free (empty) universal slots. Do not discard
3.
the filler bracket! You may require it at a later stage.
Insert the SLT Card into the guide rails of the free slot you selected for the card.
4.
Make sure that the connectors on the card make perfect contact with those on the motherboard on the
backplane.
Press down the levers on the mounting bracket to secure the card in its slot. Now, secure the mounting
5.
bracket with the two screws provided.
If you are installing more than one SLT card, you can install the second card in any other free slot. It is not
necessary to install the second/third card in the subsequent slots.
Use the cables supplied with the SLT card to connect the SLT wires with the Main Distribution Frame.
6.
For each connector on the SLT Card, there is a separate 4-pair cable with an RJ45 jack on one end and
free at the other end.
Refer the illustrations below for pin out details of each connector.
