• Positive Response to Is ANI Available signifies the Group 1 tone that the outbound end will send to
the inbound end as a response to Is ANI Available tone from the inbound end. The tone defined in this
parameter indicates the Group 1 tone with which the Outbound end will respond to the inbound end to
indicate that it has ANI digits to be sent. Valid range is 01 to 15. Default: 01.
• Negative Response to Is ANI Available signifies the Group 1 tone that the outbound end will send to
the inbound end as a response to Is ANI Available tone from the inbound end. The tone defined in this
parameter indicates the Group 1 tone with which the Outbound end will respond to the inbound end to
indicate that it does not have ANI digits to be sent. Valid range is 01 to 15. Default: 10.
• ANI End Tone Presentation Allowed signifies the Group 1 tone used to signify end of ANI digits with
Presentation Allowed. Valid range is 01 to 15. Default:15.
• ANI End Tone Presentation Restricted signifies the Group 1 tone used to signify end of ANI digits
with Presentation Restricted. Valid range is 01 to 15. Default: 00.
Inbound Parameters
• Dialed Number Identification Signal (DNIS) End Type parameter is applicable only when the DNIS
length is set to 99 (i.e. variable). The outbound end indicates end of DNIS using a group I tone or using
time out.
The range of DNIS End Type is from 00/ 01 to 15; where 00 indicates End of DNIS as time out, 01 to 15
indicates group I tone to declare End of DNIS. Default:15.
• Dialed Number Identification Signal (DNIS) Digit Length specifies the number of DNIS digits
required by inbound end to indicate the Called party number during MFC R2 signaling. Valid range is
01 to 99. Default: 99.
• Enter the Address Number Information (ANI) Request Position as per your requirement. The
inbound end may or may not request ANI digits. It may request ANI digits after receiving the first DNIS
or after receiving second DNIS or even after receiving all the DNIS digits.
The range of ANI Request Position is as follows:
ANI Request
00
01-98
99
Default: 99.
• Address Number Information (ANI) Length specifies the number of ANI digits that would be
expected by the inbound side as Calling Party Number during MFC R2 signaling. This parameter at the
inbound side guides the inbound register to switch from requesting ANI digits back to requesting DID
digits. Valid range is 00 to 99. Default: 99.
• ANI Length = 00 signifies ANI is not sent by the Outbound end.
• ANI Length = 99 signifies ANI Length is variable.
445
Meaning
Never request ANI digits
Request ANI digits on receipt of these
many DNIS digits
Request after receiving all the DNIS
digits (complete DNIS)
