• "Handling of Outgoing Calls"
• "Handling of Outgoing Calls"
• "Handling of Outgoing Calls"
Now, whenever there is a call on/ from the Port for which you have applied this feature, SARVAM UMG will match
the Called/ Calling number with the Number configured in the Automatic Number Translation Table using the best
match found logic.
• If a match is found, the system will check whether and how many digits to strip off. It will strip off digits
according to the number you have entered in the Strip Digit column. If '0' is configured in the Strip Digit
column, it will check the Add Prefix column. If configured, the system will add that prefix. If no prefix is
configured, the system will route the same number string further.
If ~ (Wait for Answer) is configured in the Add Prefix column, the system will wait for the call to mature.
Similarly, if ^ (Pause) is configured in the Add Prefix column, the system will wait for the Pause timer and
then route the call further.
• If no match is found for the Called/ Calling number in the ANT Table, the system will route the number
string, without modifying it.
Automatic Number Translation feature will not be applied when Emergency Numbers are dialed.
Automatic Number Translation also forms the basis of Multi-Stage Dialing. Using of Calling Card for making
international calls is the most common example of Multi-Stage Dialing.
While using a Calling Card, you have to dial the digits in the following sequence:
Dial the number for using the Calling Card, for example, 160223.
1.
After the call is matured, dial the PIN number printed on the Calling Card, for example, 113212.
2.
At last, dial the international number you want to call. For example, 0014162357896.
3.
Thus, you will have to dial the Calling Card number and the PIN number every time before dialing the international
number. To avoid repetitive dialing of these fixed digits for making a call, you can configure the ANT table as under.
• In Number, configure '00', the prefix for international numbers.
• In Add Prefix, configure the Calling Card server number and the PIN Number.
As the system must wait for the Calling Card server to answer before dialing the PIN, you must configure
Wait for Answer (~) between the Calling Card server number and the PIN number.
You must also insert a delay by configuring the Pause Timer (^) after the PIN number.
• Keep Strip Digit as 00.
• The Automatic Number Translation table would look like this:
Index Number
1 00
2
Matrix SARVAM UMG System Manual
under "SIP Trunk"
under "FXO Port"
under "Mobile Port"
Strip Digit
00
Add Prefix
160223~113212^
