Enabling PIN Protection on SIM
To protect the SIM card from unauthorized use, you need to provide a Personal Identification Number (PIN) on the
SIM.
To do so,
4.
• insert the SIM into a mobile handset first.
• enable PIN Protection from the mobile handset.
• assign the desired SIM PIN value.
• make sure you configure this value in SIM PIN for the Mobile Port using Jeeves. See
detailed instructions.
• remove the SIM from the mobile handset.
If you do not want to use PIN protection, insert the SIM in the mobile handset and disable PIN protection.
Remove the SIM Card from the mobile handset.
Insert the SIM card (PIN changed to the desired value), with its connector side down into the SIM holder on
5.
the Mobile card. You can insert multiple SIM cards of the same GSM service provider or of different service
providers.
Insert the Mobile card into the guide rails of the universal slot you have selected for this card. Make sure
6.
that the card is inserted deep enough to make perfect contact with the connectors on the backplane. Now,
press down the levers on the card mount bracket to secure the card in its slot.
Connect the antenna provided with the card on the splitter connector on the front panel of the card. You
7.
may also use the antenna cable to place the antenna at another position.
Repeat Steps 1-7 to insert another Mobile card.
8.
If you have completed all installations tasks, power the system.
9.
Wait for the system to register with the Mobile network. By default, the Mobile ports are set to select and
10.
register with the Mobile networks automatically. Now, observe the LED Patterns of the Mobile Ports.
• At every power up of the system, it takes about 3 minutes for the Mobile ports to get registered with the
network. Once registration with the GSM network is completed, the mobile port can be used.
• Each time the Mobile Port sends a request, such as Registration Request, the system waits for the
duration of the Network Response Timer. This Timer signifies the time for which the Mobile Port waits
for a response from the Mobile network. It is fixed as 150 seconds for all Mobile ports.
