B: INSTALLATION
1) Insert protector and plate to rear differential.
(A) Protector
(B) Rear differential member plate
2) Set rear differential to transmission jack.
NOTE:
Secure rear differential to transmission jack using
a band.
3) Install ST to rear differential.
ST 28099PA090 OIL SEAL PROTECTOR
4) Insert the spline shaft until the spline portion is
inside the side oil seal.
REAR DIFFERENTIAL FOR VA-TYPE
S303151A11
B3M1618A
G3M0256
B3M1622A
DI-43
5) Remove ST from rear differential.
ST 28099PA090 OIL SEAL PROTECTOR
6) Completely insert axle shaft into rear differential
by pressing rear differential.
7) Adjust transmission jack as required so rear dif-
ferential stud bolt is properly inserted into rear
crossmember bushing.
8) After rear differential stud bolt has been
inserted into rear crossmember bushing, raise
transmission jack to make jack rear differential
level.
Differentials
B3M1623
B3M1624
