ABS
8. G Sensor
S401183
A: REMOVAL
S401183A18
1) Disconnect battery ground cable.
2) Remove console cover.
<Ref. to EI-34, REMOVAL, Console Box.>
3) Disconnect connector from G sensor.
4) Remove G sensor from body.
CAUTION:
Do not drop or bump G sensor.
G SENSOR
B: INSTALLATION
1) Install in the reverse order of removal.
NOTE:
Do not install G sensor in the wrong direction.
There is an arrow mark on the sensor showing
which side faces the vehicle front.
G6M0095
B4M1734
ABS-22
S401183A11
B4M1729A
