Brocade Communications Systems StoreFabric SN6500B Reference page 47

The fields in the error message are described in
TABLE 5
Variable name
Sequence Number
Audit flag
Time Stamp
Event ID
Severity
Event Class
User ID
Role
IP address
Interface
Application Name
Admin Domain
Switch name
Reserved field for future
expansion
Event-specific information
Fabric OS Message Reference
53-1002749-01
Audit message field description
Description
The error message position in the log.
Identifies the message as an Audit message.
The system time (UTC) when the message was generated on the switch. The
RASLog subsystem will support an internationalized time stamp format
based on the "LOCAL" setting.
The message module and number. These values uniquely identify each
message in the Fabric OS and reference the cause and actions
recommended in this manual. Note that not all message numbers are used;
there can be gaps in the numeric message sequence.
The severity of the error, which can be one of the following:
•
1 – CRITICAL
•
2 – ERROR
•
3 – WARNING
•
4 – INFO
The event class, which can be one of the following:
•
CFG
•
CLI
•
FABRIC
•
FIRMWARE
•
FW
•
LS
•
MAPS (internal use only)
•
RAS
•
SECURITY
•
ZONE
The user ID.
The role of the user ID.
The IP address.
The interface being used.
The application name being used on the interface.
The Admin Domain, if there is one.
The defined switch name or the chassis name of the switch depending on
the action; for example, HA messages typically show the chassis name and
login failures show the logical switch name.
This value is truncated if it is over 16 characters in length.
Execute the chassisName command to name the chassis or the switchName
command to rename the logical switch.
This field is reserved for future use and contains a space character (null
value).
A text string explaining the error encountered and providing parameters
supplied by the software at runtime.
Reading the system messages
Table 5.
