Creating Autostep Files
AWG2021 User Manual
In this operation, you will program waveforms to be output, using the files you
have created in the previous operations to form an autostep file.
1. Select New Autostep on the second page of the side menu in the initial
EDIT menu.
NOTE. Select More from the side menu to display the next page.
You will set the CH1 file for Step 1.
2. Using the general purpose knob, move the cursor to the CH1 file column.
Figure 2 44: Moving the Cursor
3. Press the VALUE button on the front panel.
The list used to select waveforms or sequence files will appear.
Operating Examples
2 57
