SETUP Menu
3 218
To select a waveform or sequence file:
1. Select Waveform Sequence from the bottom menu. The waveform display
area will be highlighted on the screen.
2. Select the channel for setting in the side menu.
3. Turn the general purpose knob to open the file list. Use the general purpose
knob to select the desired waveform or sequence file from the list.
4. After the file has been selected, select O.K. in the sub-menu. The selected
file will be confirmed and the waveform and file name will appear in the
icon, as shown in the figure below.
When the file is confirmed, the output parameters for that file will be set
automatically.
