EDIT Menu
Entering the Sequence
Editor
Saving Files and Exiting
the Editor
Sequence Editor Menu
Structure
Sequence Editor
3 162
1. Press the EDIT button in the MENU column. The initial EDIT menu will
appear.
2. Select Edit or New Sequence from the side menu.
Edit
New Sequence
The sequence editor screen will appear.
Use Exit/Write in the bottom menu to save the file to the internal memory of the
AWG2021 and exit from the editor depending on the selected side menu item.
The same procedure is used to save the file and exit from the equation editor as
for the waveform editor. See "Saving Files and Exiting the Editor" in the section
on the waveform editor.
The Sequence Editor menu has the structure shown in Figure 3 -120.
Bottom Menu
Operation
Show Overview
*2
Undo
Exit/Write
*1 This item appears in the side menu when a sequence file (XXX.SEQ) has been selected with Catalog in the
menu.
*2 This item appears when Operation in the bottom menu has been selected.
Figure 3 120: Sequence Editor Menu Structure
Used to select and edit an existing sequence file
(.SEQ)
Used to create a new sequence file
Side Menu
Cut Line
Copy to Buffer
Paste from Buffer
Show Catalog Entry
Insert Contents of Sequence
Write and Exit
Exit without Writing
Write
*1
