Overview
Side Panel
Figure 2 3: Side Panel
2 8
21
LED Indicator
(21) Floppy Disk Drive
Note. Never press the eject button to eject the floppy disk while the disk drive indicator light is
lit, as the stored data may be corrupted and errors may result.
Eject Button
The floppy disk drive is used for storing various types of files.
Files can be loaded or saved from/to floppy disk using the
LOAD/SAVE menu. When the disk drive is in operation, the
LED indicator is lit. Remove a floppy disk by pressing the eject
button.
