1. Select Amplitude from the bottom menu.
2. Select CH2 from the side menu.
3. Press the Track key in the side menu and select CH1. The linkage setting
will appear below the CH2 amplitude icon.
4. Select CH1 from the side menu.
5. Turn the general purpose knob to change the CH1 amplitude. Check to make
sure that the CH2 amplitude has changed accordingly.
The same procedure can be used to link the offset values for other channels
to the CH1 waveform. In such cases, the linkage setting will be displayed
below the CH2 offset icon.
